Applaction: Linear measuring instrument
Be made from material: common PP（polypropylene)
Color: white
*Slop surface should be clean
whole part with no burrs
*General Radius on edges 0.1+/-0.05
(no Radius at end edges of dimensions 0.2 and 0.3, too narrow to allow it.)
*Without oxidation on steel
*Tolerance control for outer circle： +/-0.1
Plastic injection tooling: 1 x 8 cavities (Sept. 14th, 2020)
*Dimension 1.0~0.8 change to: 1.0 ~ 0.92, use 0.96mm standard for tooling work
Actual dimension control of part as below:
Top: 24.8(24.8), 27.4(27.4)
Bottom: 52.77゜(45゜), 0.2(0.2), 0.96(1.0~0.92), 26.8(26.8)
